Description
* Computer (PLC) controlled touch panel: 8.4 “TFT color LCD screen, 60x 480 pixel resolution, 2ad.usb 2.0 input (program on desktop), animated, CE, UL, MIC certified, 140 different programs, 64 MB RAM, Turkish and English standard programming languages, Error warning diagnostics feature, The ability to manually control the functions of the machines on the screen, digitally adjust the pressing pressure on the screen, digital distance control, program copy feature, the number of ironed work counts, coating time warning.
* Gradual steaming feature, Gradual upper and lower vacuum (more or less)
* Energy saving is achieved with serpentine aluminum molds.
* Security system in CE norms
* Robust construction and ergonomic use.
* Upper and lower molds are covered with European material.
* Precision mold design with advanced technology CNC surface treatment.
* Anti-glare sections in the upper mold, environmental (edge) vacuum system.
* Ability to do more and faster work with one operator
* Placing the product properly with laser marking beam
* Fixing the product with the vacuum of rotation
* Hand iron and safety ironing pad for touch-up operations.
Technical data
Capacity (parts / h) 120-150
Electricity (V) 230
Resistance Power (kW)
Motor Power (kW)
Pump Power (kW)
Steam Entrance (“) 3×1 / 2”
Steam Outlet (“) 3×1 / 2”
Air Inlet (“) 1/2”
Vacuum Inlet (“) 4×1-1 / 2”
Steam Consumption (kg / h) 30
Air Consumption (lt / d) 85
Steam Pressure (bar) 5 – 6.
Air Pressure (bar) 5 – 6.
Net Weight (kg) 920
Packed Weight (kg) 1040
Net Size (cm) 266x270x220
Packed Size (cm) 276x280x230
